Alloy 601 Round Bar is a high-performance nickel-chromium alloy renowned for its exceptional oxidation resistance, high-temperature strength, and excellent mechanical properties. Below is a detailed description of its composition, characteristics, and applications:

Composition

Alloy 601 is primarily composed of:

• Nickel (Ni): 58-63% – Provides excellent corrosion resistance and high-temperature strength.

• Chromium (Cr): 21-25% – Enhances oxidation and corrosion resistance.

• Iron (Fe): Balance – Forms the base of the alloy.

• Aluminum (Al): 1.0-1.7% – Improves oxidation resistance by forming a protective oxide layer.

• Other Elements: Small amounts of silicon (Si), manganese (Mn), and copper (Cu) may also be present.

• Grade	UNS	Density	Tensile Strength (MPa min)	Yield Strength (MPa min)	Reduction of Area min (%)	Elongation min (%)	Hardness (HRC)
  INCONEL 601	N06601	8.11	550MPa	205MPa min	/	40% min	/



  Chemical Composition(%):

  Ni	Cr	Al	Fe	C	Mn	Si
  58.0-63.0	21.0-25.0	1.0-1.7	Balance	0.1max	1.0max	0.5max
  S	Cu
  0.015max	1.0max

Key Properties

• Oxidation Resistance: Alloy 601 exhibits outstanding resistance to oxidation at high temperatures (up to 2200°F or 1200°C) due to the formation of a stable, adherent oxide layer.
• High-Temperature Strength: The alloy maintains excellent mechanical properties at elevated temperatures, making it suitable for high-temperature applications.
• Corrosion Resistance: It resists corrosion in various environments, including sulfur-containing atmospheres and carburizing conditions.
• Thermal Stability: Alloy 601 retains its structural integrity under cyclic heating and cooling conditions.
• Weldability: The alloy is easily weldable using common welding techniques, and it retains its properties in welded conditions.

Applications:

Alloy 601 round bars are used in industries where high-temperature strength and oxidation resistance are critical. Common applications include:

• Aerospace: Combustion chambers, afterburner components, and heat shields.
• Heat Treating: Furnace muffles, radiant tubes, and heat exchangers.
• Power Generation: Gas turbine components and exhaust systems.
• Chemical Processing: Reactors, heat exchangers, and piping systems.
• Industrial Furnaces: Retorts, baskets, and fixtures.

Mechanical Properties:

• Tensile Strength: 80-120 ksi (550-827 MPa)

• Yield Strength: 30-60 ksi (207-414 MPa)

• Elongation: 30-45% (in 2 inches)

• Hardness: 150-200 HB (Brinell Hardness)

Advantages of Round Bar Alloy 601:

• Superior oxidation resistance at high temperatures.
• Excellent mechanical properties at elevated temperatures.
• Good resistance to thermal fatigue and cyclic heating.
• Versatility in fabrication and welding.
• Long service life in demanding environments.
